When working with 3D models a lot of calculation and memory may be required for certain operations. This sets the resolution/quality for the 3D model. With this option checked, your drawings will be re-sized to remain in the same proportion and relative position within your new material extents when you click OK. If you wish to preserve the existing size of your drawings, even after the job size has changed, leave this option unchecked. When editing the Job Size parameters of an existing job, this option determines whether any drawings you have already created will be scaled proportionally to match the new job dimensions. Aspire uses that information to correctly manage the alignment of the geometry relating to each side. This section gives choice between horizontal and vertical flipping when changing machining side. This option allows the datum position to be set to a value other than X0, Y0. While this form is open, a red square is drawn in the 2d view to highlight the datum's position. This represents the location, relative to your design, that will match the machine tool when it is positioned at X0, Y0. This datum can be set at any corner, or the middle of the job. This option allows Z Zero to reference the same physical location, regardless whether material is flipped or not XY Datum Position Indicates whether the tip of the tool is set off the surface of the material (as shown in the diagram) or off the bed / table of the machine for Z = 0.0. It also allows you to select which units of measurement you prefer to design in - either inches (Imperial/English) or millimeters (Metric). This section of the form defines the dimensions of the material block you will be using for your project in terms of width (along the X axis), height (along the Y axis) and thickness (along the Z axis). See the Sketchup section for detailed instructions on importing Sketchup files. SKP extension (see can be imported as 2D data suitable for machining.

Vectric vcarve pro software pdf#

When importing multiple page PDF documents each page is placed on a separate layer. The text and vector content of PDF files is extracted when imported into VCarve Pro.

Vectric vcarve pro software software#

Software such as the Adobe product range can be used to convert files from other design and word processing software into the industry standard PDF file format. The AI file will be placed with the lower left corner of the design at X0, Y0 The Job Setup form will automatically be opened so the required material size can be specified. By default the EPS file will be placed with the lower left corner of the design at X0, Y0.įiles from typical design software such as Adobe Illustrator and Corel Draw can be opened. The actual size of the material can then be specified along with the required thickness and appropriate X0, Y0 and Z0 origins.įiles from typical design software such as Corel Draw can be opened. The Job Setup Form is automatically opened showing the maximum X and Y dimensions of the opened design. All calculated toolpaths are stored/opened from the CRV file.įiles from other CAD or graphics software packages such as AutoCAD will be opened in the original size and position.

Vectric vcarve pro software pro#

All calculated toolpaths are stored/opened from the CRV3D file.įiles previously created and saved in VCarve Pro will be opened and displayed in the 2D Design window.

Vectric vcarve pro software update#

Free update for any major version updates for the first year.

Vectric vcarve pro software professional#

Having simplicity at their core principle, they still haven’t lost the professional level needed for the

Vectric have withheld their reputation of making software easy by concentrating not only on ease of use, but also simplify operations, and making the whole process much more logical.

3D Components can be displayed in various materials and colours to give an accurate representation that can be presented to customers or clients. Working with 3D Shapes from 2D vectors is very interactive, in Aspire any changes are instantly updated in the 3D View to show exactly what the final result will look like. Vectric have developed a unique approach to 3D Modelling with Aspire, models can be easily built up from simple shapes, and modified at anytime without having to recreate the component. Aspires 3D component modelling coupled with the extensive 2D tools makes it easy to work on existing 2D and 3D Models as well as create your own from scratch.
